Scott Gambler 710
The all NEW SCOTT Gambler 710 is our GSTAAD-SCOTT World Cup DH Replica. Now available with 27.5” wheels, this rig is a no compromises DH weapon. With a custom race tuned Kashima Coated FOX Suspension and World Cup podium proven components, this bike was built for speed. Equipped with a low and slack geometry, a long shock and a tweaked leverage ratio, the Gambler 710 will be able to handle everything in front of you. Following our belief that for every track there is a correct tool, this bike has been designed to be able to be converted to run 26” wheels as well.
Ram Gambler Alloy 6061 Hydroformed custom butted PF BB107 / IDS X DH 12x150mm Dropout BB height adjustable ISCG05 / 210mm rear travel Travel 203mm
Gaffel eller ev. stötdämpare fram Fox 40 RC2 FIT Factory 27.5 203mm travel /Kashima / Air Spring preload adj. / Reb-Comp High & low speed adj. 20mm thru axle / alloy steerer
Stötdämpare bak FOX DHX RC4 Coil Kashima Reb. / low-speed comp / Bottom out force adj. custom tuned / 267x89mm spring rates S 250 / M 300 / L 350
Styrlager Syncros DH adjustable semi integrated / adj +-1° or +-2° with cup ID 49.6mm / OD 55mm
Växelförare bak Shimano Saint RD-M820-SS short cage / 10 Speed
Växelhandtag Shimano Zee SL-M640 Rapidfire Plus / 2 way release
Bromshandtag Shimano Zee BL-M640
Bromsar Shimano Zee BR-M640 Disc 4 Piston / 203mm / SM-RT76L Rotor
Vevparti Shimano Saint FC-M825 36 T alloy chainring Hollowtech II / 165mm Chainguide E.thirteen LG-1 ISCG05 / w/Taco alloy backplate
Vevlager Shimano SM-BB71-41A Shell 104.5x41mm
Styre Syncros DH1.5 35mm / 800mm / 20mm Rise Syncros Pro DH dual lock-on grips
Styrstam Syncros DH1.5 35mm / Direct Mount 42-47mm ext
Sadelstolpe Syncros FL1.5 / 31.6 / Alloy7050
Sadel Syncros DH2.0 / CrMo Rails
Nav fram DT Swiss 370 / 110 x 20mm thru axle
Nav bak DT Swiss 350 150 × 12mm thru axle / sealed bearings
Kedja Shimano CN-HG54
Kassett eller ev. drev bak Shimano CS-4600 / 11-25 T DH cassette
Ekrar DT Swiss Competition / 2.0/1.8 black
Fälgar DT Swiss FR570 / 27.5 / 32H black
Däck Schwalbe Downhill Evolution Line Front: Magic Mary 27.5 × 2.35 VertStar Rear: Magic Mary 27.5 × 2.35 TrailStar Triple Nano Compound Supergravity
Vikt i kg 17.50kg
Vikt i lbs 38.58lbs
S S M M L L
BB setting low BB setting high BB setting low BB setting high BB setting low BB setting high
Head tube angle 63.0 ° 63.7 ° 63.0 ° 63.7 ° 63.0 ° 63.7 °
Head tube length 115.0 mm 115.0 mm 115.0 mm 115.0 mm 115.0 mm 115.0 mm
Top tube horizontal 549.7 mm 546.2 mm 595.4 mm 591.5 mm 633.6 mm 629.3 mm
Standover height 778.6 mm 783.6 mm 771.6 mm 777.1 mm 765.3 mm 771.3 mm
Bottom bracket offset -13.0 mm -3.0 mm -13.0 mm -3.0 mm -13.0 mm -3.0 mm
Bottom bracket height 343.0 mm 353.0 mm 343.0 mm 353.0 mm 343.0 mm 353.0 mm
Wheel base 1,175.8 mm 1,172.5 mm 1,205.8 mm 1,202.5 mm 1,235.8 mm 1,232.5 mm
Bottom bracket center to toptube center 336.0 mm 336.0 mm 333.0 mm 333.0 mm 331.0 mm 331.0 mm
Bottom bracket center to top of seattube 406.0 mm 406.0 mm 404.0 mm 404.0 mm 403.0 mm 403.0 mm
Seat angle 75.1 ° 75.9 ° 73.7 ° 74.6 ° 73.0 ° 73.9 °
Chainstay 425.0 mm 421.5 mm 425.0 mm 421.5 mm 425.0 mm 421.5 mm
Reach 712.0 mm 712.0 mm 712.0 mm 712.0 mm 712.0 mm 712.0 mm
Stack 385.0 mm 393.0 mm 415.0 mm 422.8 mm 445.0 mm 452.6 mm
Stem length 616.7 mm 611.7 mm 616.7 mm 611.4 mm 616.7 mm 611.2 mm
Beskrivning av utvalda cykelegenskaper
Tracks differ, as do riding styles and riders. With that idea in mind, we tried to design a bike that allows you to decide on set up based on your specific needs. With the available geometry adjustments the Gambler can have almost the same geometry with either wheel size. Thanks to adjustable BB heights, chainstay lengths and head angles we were able to create a seriously fast bike regardless of whether you want to run 26” or 27.5” wheels. Why compromise if you don't have to?
IDS-X Dropouts. Simpler, stiffer, lighter
The IDS-X Dropouts have a unique axle and dropout interface which locks the axle into place. This design eliminates the need for pinch bolts on the rear axle. We were tired of the rear ends of bikes coming loose after long days in the bike park so we set out to find a solution. After many one off prototypes we found this solution in the form of eccentric and conical shapes on the axle and dropouts. These shapes key into each other and lock the rear end down tight. In addition, the stiffer feeling rear end provides for better and more consistent cornering traction over traditional axle/dropout designs.
The heart of the Gambler is the Floating Link. Combining just the right amount of support with incredible comfort at high speeds, the linkage was optimized for use with the new FOX RC4. When FOX shifted to the smaller shaft on the RC4 we realized that a new kinematic was necessary. The Floating Link pivots around an imaginary floating point allowing the designers to fine tune all aspects of the leverage ratio enabling the shock and linkage to function in glorious harmony.This linkage allowed the engineers to decrease the shock hardware rotation from 36 degrees to 9 degrees on one end and 12 degrees down to 4 degrees on the other end. This not only increases durability but also improves small bump sensitivity. Furthermore, unlike most bikes on the market, the bearing loads are drastically decreased at the beginning of the shock stroke further enhancing traction performance.
Chain stay length adjustment
Adjustability has always been one of the Gamblers strong points over the years. The Gambler 700 is no different. The rear end has two chainstay length settings, providing for ideal setups anytime, anywhere. In the low BB setting, the longer 440mm setting is designed to work best for high speed tracks or riders who like a planted rear end. The @Brendog1 approved, shorter 425mm chain stay setting gives the bike a lively feel and works better on tighter tracks. With the higher BB setting, the available chain stay lengths are 421mm and 435mm.
Adjustable head angle
The Gambler 700 has a stock head angle of 63 degrees. Thanks to the provided Syncros Angled Headsets in 1 degree and 2 degrees you have access to a range 61 degrees to 65degrees. This range of head angles provides the opportunity to choose the ideal setup for any racer on any track. Horses for Courses.
Adjustable bottom bracket height
The BB height on the Gambler 700 is adjustable by 10mm to accommodate for rider preference as well as wheel size. If you want to set up your rig to carry speed through a corner with a low BB or to smash on the pedals to get back up to speed on a higher BB, you have the flexibility to choose. With a 27.5” wheel set up, you can either have a 343mm BB height in the low position with or a 353mm BB height in the high position, enabling the rider to pick from a low and slack carver of a bike or a pedal smashing flat track weapon. The 26” setup works much the same way with a 341mm BB height in the high position or a 331mm BB height in the low position.
Integrated fork bumpers
The integrated fork bumpers on the Gambler 700 not only protect the cables from getting pinched by the fork in a crash but also protect the frame from the fork in that very same crash. Gone are the days of dimpled top tubes and pinched cables. Lighter, simpler and no room for error- these are the principles behind the new Gambler 700 fork bumpers.
